CAMEO LIGHTS ZENIT Z180 G2

CAMEO LIGHTS ZENIT Z180 G2

Professional Zoom PAR IP65



Item No.: CLZZ180G2



  • Powerful, professional IP65 PAR spotlight with 10–40° zoom

  • 180 W RGBW COB LED

  • Fast, flexible mounting options via patented SPIN16® technology, featuring a mounting bracket with an integrated 16-mm TV spigot

  • High-resolution colour blending and dimmer response with 16-bit technology

  • Colour temperature correction

  • Variable white balance

  • 4 high-resolution dimmer curves with variable response

  • Easy configuration via OLED display with 4 illuminated touch-sensitive controls

  • Access lock against unauthorised changes to the menu settings

  • Fully RDM enabled

  • Flicker-free: perfect for TV and film applications

  • 5-pin DMX sockets and IP65-rated powerCON TRUE1-compatible power sockets

  • Optional Cameo Omega bracket (CLOMEGABRACKET1) available as an accessory
  • Description

    Versatile, rapid installation and simple, practical configuration – the ZENIT® Z 180 G2 is the new shining star. Thanks to our innovative, patented SPIN16® technology, it is mounted in an instant using the mounting bracket’s 16-mm TV spigot and a super clamp. The powerful RDM-enabled PAR spotlight for demanding professional applications now has a bright OLED display menu. The long-lasting 180 W RGBW COB LED and 16-bit technology create consistent, high-resolution colour blends and perfect dimming response. With a range of 10° to 40°, the motor zoom provides flexible illumination ranging from sharp, narrow beams to widely spread expanses.



    With its flicker-free operation via 6 selectable PWM frequencies and its IP65 classification, the ZENIT® Z 180 G2 is perfectly suited for use with film cameras or outdoors. The PAR spot also features colour temperature correction, a variable white balance and 4 selectable dimmer curves, whose response can be adjusted to simulate halogen lamps.



    The ZENIT® Z 180 G2 can be controlled via 7 DMX modes or used as a master, slave or standalone unit. The bright OLED display with 4 illuminated touch-sensitive controls makes menu navigation and configuration child’s play, while an access lock prevents unauthorised setting changes. For almost silent operation, the extremely robust die-cast aluminium housing is equipped with a temperature-controlled fan. 5-pin DMX sockets and powerCON TRUE1-compatible power input and output facilitate easy parallel connection. The Cameo ZENIT® Z 180 G2 runs on all voltages between 100 and 240 volts.

  • Specification

    Product type LED PAR Lighting
    Type Outdoor
    Colour spectrum RGBW
    Number of LEDs 1
    LED type 180 W COB
    LED PWM Frequency 800 Hz, 1200 Hz, 2000 Hz, 3600 Hz, 12 kHz, 25 kHz - adjustable
    Dispersion 10 - 40 °
    DMX input IP65 , XLR 5-pin male
    DMX output IP65 , XLR 5-pin female
    DMX mode 10-channel , 11-channel , 17-channel , 3-channel , 4-channel , 5-channel , 9-channel
    DMX Functions Colour Blending , colour change , colour macro , Colour temperature correction , Dimmer , Dimmer Fine , Dimmer response , RGBW , RGBW Fine , Stroboscope , Various system settings , Zoom , Zoom Fine
    Standalone modes Auto programs , colour macro , Master/Slave Mode , Static Mode , strobe , Tunable White , User Colours
    System settings Colour calibration , Dimmer Curves , Dimmer response , Display Lock , DMX Fail , Factory reset , Fan controller , LED PWM Frequency , Lighted Display , Rotate display by 180 , Zoom Reset
    Control DMX 512 , RDM enabled
    Controls Down , Enter , Mode , Up
    Indicators OLED Display
    Operating voltage 100 V AC - 240 V AC, 50 - 60 Hz
    Power consumption 220 W
    Power connector IP65 , Power Twist
    Ambient temperature (operating) -15 - 45 °C
    Housing material metal
    Cabinet colour Black
    Protection class IP IP65
    Cooling temperature-controlled fan
    Illuminance 56,790 lx @ 1 m (narrow)
    Luminous flux 4900 lm
    Other features 1 x omega mounting , Flap , IP65 Power Twist connector , Power cord , TV spigots 16 mm
    Width 240 mm
    Height 240 mm
    Length 254 mm
    Weight 8,2 kg
