CAMEO LIGHTS ZENIT P40

CAMEO LIGHTS ZENIT P40

$0.00Price
Professional Outdoor PAR Can IP65 with innovative light shaping diffusors

Item No.: CLZP40LSD

  • Professional IP65 outdoor PAR can with 4 x 10 W RGBW Osram OSTAR LEDs and 8° beam angle

  • Includes 2 innovative light shaping diffusers for beam angles of 25° or 45° while maintaining transmission efficiency

  • RDM capability

  • 16-bit technology for high-resolution Colours and dimming

  • Flicker free, ideal for motion picture and TV applications

  • Colour temperature and individual LED colour correction

  • 4 ultra smooth dimming curves and adjustable halogen lamp-like dimming response

  • 7 modes of DMX control plus master, slave and standalone capability

  • OLED display with 4 touch buttons for easy configuration

  • Security lock against unauthorized menu access

  • Convection cooling for noise-free performance

  • Description

    The Cameo Zenit® P40 is an IP65 rated outdoor PAR can with a sharp, tightly focussed beam angle of 8°. For an additional choice of 25° or 45° angles, it comes with two ultra-efficient light shaping diffusers which are specially designed to maintain the fixture's powerful illuminance. The Zenit® P40 is equipped with four 10W RGBW Osram OSTAR LEDs for brilliant, uniform Colours while 16-bit technology enables high-resolution Colour mixing and dimming. With a 3,600 Hz refresh rate and flicker-free operation the advanced Zenit® P40 is the perfect choice for motion picture and TV applications. Highly effective convection cooling ensures totally noise-free operation.



    Truly professional, the Zenit® P40 is RDM-compatible and includes 7 modes of DMX control, exciting automated programs as well as master, slave and standalone capability. It features Colour temperature and individual LED Colour correction, a high- speed strobe, 4 selectable dimming curves and adjustable halogen lamp-like dimming response. A security lock prevents unauthorized menu access.



    To enable easy daisy-chaining, the heavy-duty die-cast aluminium housing provides innovative locking 5-pin DMX and AC power inputs and outputs. A modern OLED display with 4 touch buttons allows easy, intuitive configuration.

  • Specification

    Product type LED PAR Lighting
    Type Outdoor
    Colour spectrum RGBW
    Number of LEDs 4
    LED type 10W Osram OSTAR LED (approx.50.000 operating hours)
    Refresh rate 3600 Hz
    Dispersion 13,5° Field ° , 7° beam °
    DMX input 5-pin IP65
    DMX output 5-pin IP65
    DMX mode 10-channel , 15-channel , 2-channel , 3-channel , 4-channel , 8-1 Channel , 8-2 Channel
    DMX Functions colour fade , colour jump , colour macro , CTC (Colour Temperature Correction) , Dimmer , Dimmer Curve , Dimmer Fine , Dimmer Response , reset , RGBW , RGBW Fine , strobe
    Standalone modes Auto programs , colour fade , colour jump , colour macro , Dimmer Curve , Dimmer Response , Display Lock , Master / Slave mode , static colour , strobe , White Balance adjustable
    Controls Enter , Mode , Value Down , Value Up
    Indicators OLED Display
    Operating voltage 100 V AC - 240 V AC, 50 - 60 Hz
    Power consumption 50 W
    Power connector IP65
    Housing material die-cast aluminium
    Cabinet colour Black
    Protection class IP 65
    Cooling Convection
    Illuminance 25200lx @ 1m
    Luminous flux 1200 lm
    Operating Temperature -15 - 45 °C



    Dimensions without mounting bracket

    Width 186.6 mm
    Height 186.6 mm
    Length 159 mm
    Weight 4,8 kg
    Features IR Remote Control
