LD SYSTEMS STINGER 8 A G3

LD SYSTEMS STINGER 8 A G3

$0.00Price
Active 8" 2-way bass-reflex PA speaker

Item No.: LDEB82AG3

  • 2-way active 8” bass reflex PA speaker

  • High-efficiency 300 watts RMS digital power stage and 129 dB max. SPL

  • Multi-purpose design for fullrange, satellite and monitor applications

  • Application presets for quick frequency response contouring

  • BEM optimized HF waveguide for uniform coverage

  • 8” custom woofer and BMS compression driver

  • DynX® DSP technology for distortion-free performance

  • 2 line/mic input channels with individual gain controls plus mono mix out

  • 12 mm birch ply cabinet with ultra rugged polyurea finish and M10 suspension points

  • Shock-resistant front grill provides maximum speaker protection

  • 36 mm Dual-Tilt pole receptacle for 0° or 5° mounting angles

  • Large selection of smart installation and transport accessories

  • Description

    Engineered for rock-solid reliability day in, day out this active 2-way system is a truly professional performer. With its multi-purpose bass reflex construction and carefully contoured, user-friendly presets it is equally suitable for fullrange, satellite or floor monitor applications. The Stinger® 8 A G3 is powered by high efficiency Class D amplification with a hefty 300 watts RMS output. It drives a custom designed 8” woofer and BMS compression driver delivering a punchy low end and smooth, crisp highs. The HF waveguide has been designed using BEM, the numerical modeling of sound radiation and propagation. It reduces floor and ceiling reflections, effectively eliminates side lobes and achieves a controlled uniform coverage pattern. The Stinger® 8 A G3 incorporates LD Systems’ proprietary DynX® DSP technology to ensure top-level performance with maximum clarity and punch at all times. Processing includes crossover and multiband limiter functions for accurate time alignment and pristine, distortion-free audio. Designed to be a real workhorse throughout, the enclosure is made of rigid birch ply and coated with ultra tough polyurea for extraordinary strength and durability. Sporting a steel front grille, Dual-Tilt pole receptacle, multiple suspension points and ergonomic handles the Stinger® 8 A G3 is an attractively priced choice for truly professional sound reinforcement. A large selection of accessories facilitate live and installed applications.

  • Specification

    Product type PA loudspeaker
    Type active
    Low/mid driver dimensions 8 "
    Woofer size 203.2 mm
    Woofer magnet Ferrite
    Woofer brand Custom-made
    Woofer voice coil 2 "
    Woofer voice coil (mm) 50.8 mm
    Horn BEM optimized CD Horn
    HF driver dimensions 1 "
    HF Driver Size 25.4 mm
    HF driver magnet Ferrite
    HF driver brand BMS
    HF driver voice coil 1 "
    HF Driver Voice Coil 25.4 mm
    Amplifier Class D
    Dispersion (H x V) 90 x 50 °
    RMS 300 W
    Peak power 600 W
    Frequency response 70 - 20000 Hz
    Max. SPL (peak) 125 dB
    Protection circuits Multiband limiter , over voltage , over-current , thermal overload
    Input sensitivity -9 dBu
    Controls 2 x gain , 2 x Mic/Line , Mode
    Indicators Limit , Mic , Mode , On , Protect (protection circuit engaged) , Signal
    Line inputs 2
    Line input connectors 6.3 mm jack , XLR
    Line outputs 1
    Line output connectors XLR
    Operating voltage 100 - 120 V / 50 - 60 Hz or 200 - 240 V / 50 - 60 Hz (automatic switching) , Switching power supply
    Operating Temperature 0 - 40 °C
    Relative Humidity < 80% (non-condensing)
    Cabinet material 12 mm Plywood
    Cabinet surface Polyurea
    Cabinet construction vented
    Width 270 mm
    Height 457 mm
    Depth 290 mm
    Weight 10,5 kg
