Cameo INSTANT HAZER 1400 PRO

Cameo INSTANT HAZER 1400 PRO

Hazer with Microprocessor Control



Item No.: CLIH1400PRO



  • Microprocessor controlled 1400 Watt Hazer

  • Max. output volume 991 m³ per minute

  • Long-lasting evaporation tube made of stainless steel 316

  • Automatic self-cleaning

  • Output and fan individually adjustable in 100 increments

  • 2-channel DMX control and standalone mode

  • Built-in insert for fluid canisters up to 5 L

  • Whisper-quiet operation

  • Ideal for TV, film, theatre, discos and live events

  • Enriches the effect of any light show
  • Description

    With a maximum output volume of 991 m³ per minute, an extremely short warm-up time of only 45 seconds and whisper-quiet operation, the Instant Hazer 1400 Pro from Cameo's Instant series is perfect for discos, live events, theatres, TV and film.



    The highly efficient micro-processor-controlled hazer features a durable evaporation tube made of austenitic stainless steel and automatic self-cleaning to prevent clogging and minimise maintenance. Haze output is consistent without additional heating and - like the fan speed - is adjustable in 1% increments for stages and rooms of any size. At full output, fluid consumption is only 17 ml per minute.



    The Instant Hazer 1400 Pro can be controlled via DMX in 2-channel mode and can also be used stand-alone. It is equipped with 3-pin and 5-pin DMX inputs and outputs. The robust construction features a 3-digit LED display, a slot for fluid canisters up to 5 litres and is protected against overheating. The Cameo Instant Hazer 1400 Pro generates a very fine, long-lasting haze to enhance any light show with effective, atmospheric effects.



    For best results, use only Cameo Instant Haze fluid, which has been developed specifically for Cameo hazers. Use of other fluids will void the warranty and may damage the device.

  • Specification

    Product type Fog and Wind Machines
    Type hazer
    Power 1400 W
    Max. Output 991 m³/min
    Warm-up Time 45 sec.
    Fluid Consumption 17 ml/min (100% Output)
    DMX input XLR 3-pin male , XLR 5-pin male
    DMX output XLR 3-pin female , XLR 5-pin male
    DMX mode 2-channel
    DMX Functions fan , Vapour Volume
    Standalone modes fan , Vapour Volume
    Controls Start/Stop/Mode , Value Down , Value Up
    Indicators 3-segment LED display
    Operating voltage 240 V AC, 50 Hz
    Power consumption 1400 W
    Overheating Protection heating element with thermostat
    Power connector Power cord with safety plug (Type E / CEE 7/7)
    Cabinet colour Black
    Recommended Fluid INSTANT HAZE (not included)



    Total dimensions

    Width 345 mm
    Height 300 mm
    Depth 365 mm
    Weight 14,21 kg
